JUPITER Z1
Jupiter Z1
CASH & CREDIT
Syarat: KTP + KK
Proses cepat 1-2 Hari
DP Bayar di Tempat Saat Motor Datang
| Tipe Mesin | Air cooled 4-stroke, SOHC |
| Jumlah / Posisi Silinder | Single Cylinder / Mendatar |
| Diameter x Langkah | 50,0 x 57,9 mm |
| Perbandingan Kompresi | 9,3 : 1 |
| Daya Maksimum | 7,4 kW / 7750 rpm |
| Torsi Maksimum | 9,8 Nm / 6750 rpm |
| Sistem Starter | Elektrik Starter & Kick Starter |
| Sistem Pelumasan | Basah |
| Kapasitas Oli Mesin | Total = 1,00 L ; Berkala = 0,80 L ; Ganti filter oli = 0,85 L |
| Sistem Bahan Bakar | Fuel Injection |
| Tipe Kopling | Basah, Multiplat, Centrifugal automatic |
| Tipe Transmisi | Constant mesh, 4-kecepatan |
| Tipe Rangka | Backbone |
| Suspensi Depan | Teleskopik |
| Suspensi Belakang | Swing Arm |
| Ban Depan | 70/90-17 M/C (38P) |
| Ban Belakang | 80/90-17 M/C (44P) |
| Rem Depan | Single Disc Brake |
| Rem Belakang | Drum Brake |
| P X L X T | 1935mm x 680mm x 1065mm |
| Jarak Sumbu Roda | 1240mm |
| Jarak Terendah Ke Tanah | 150mm |
| Tinggi Tempat Duduk | 765mm |
| Berat Isi | 101 kg (Spoke wheel) ; 102 kg (Cast wheel) |
| Kapasitas Tangki Bensin | 4,1 L |
| Sistem Pengapian | TCI |
| Battery | YTZ4V/GTZ4V |
| Tipe Busi | NGK/CR6HSA |
